Apocrine
adenocarcinoma of the eyelid
Sultan
S Aldrees1,2, Pablo Zoroquiain1 , Sarah A Alghamdi1,
Patrick Logan1 , Conrad Kavalec3, Miguel Burnier1,3
1The
Henry C. Witelson Ocular Pathology Laboratory, McGill University, 1001 Boul Decarie, Montreal H4A 3J1, Canada
2Department
of Ophthalmology, King Saud University, PO Box 245, Riyadh 11411, Saudi Arabia
3Department
of Ophthalmology, McGill University, 5252 Boul
de Maisonneuve ouest, Montreal H4A 3S5, Canada
Correspondence
to:
Pablo Zoroquiain. The Henry C. Witelson Ocular Pathology Laboratory, McGill University, 1001 Boul Decarie, Montreal H4A 3J1, Canada.
zoroquiain@gmail.com
Received: 2015-06-14
Accepted: 2016-03-07
DOI:10.18240/ijo.2016.07.26
Citation: Aldrees SS, Zoroquiain P,
Alghamdi SA, Logan P, Kavalec C, Burnier M. Apocrine adenocarcinoma of
the eyelid.
Int J
Ophthalmol
2016;9(7):1086-1088
Sweat gland
neoplasms of the ocular region are rare[1]. Traditionally, these lesions are classified as
either of eccrine or apocrine origin. The cardinal feature of apocrine tumors
includes having apical decapitation secretions from the cells rather than
forming simple secretory units with tubules, such as the case with their
eccrine counterpart[2-4]. Apocrine lesions can be both benign and malignant.
There are only 22 cases of apocrine adenocarcinoma
(AC) involving the eyelid in the English literature[2,5]. In the present series, we show two primary AC of the
eyelid with a broad morphological spectrum and with extensive
immunohistochemical analysis.
Case 1 A 59-year-old female
presented with a left lower lid lesion that has recurred for over 2y. The
lesion was diagnosed clinically a chalazion and has been excised twice since it
first appeared at another hospital without further histopathological
evaluation; however, it progressed clinically to become red and nodular with
projections and was associated with madarosis (Figure 1). On clinical
examination, no lymph node enlargement was noticed. An incisional biopsy was
then obtained and microscopic analysis of the tumor revealed a dermal tumor composed of
epithelial cells forming tubules and papillary structures with no attachments
to the overlying epidermis. At higher magnification, the cells were columnar to
cuboidal with eosinophilic cytoplasm showing apical decapitation. The nuclei
were mildly polymorphic with small nucleoli. The infiltrative tumor border
reached the margins of the biopsy and vascular invasion was observed. A
diagnosis of AC of the eyelid was made. The lesion was then excised and the
surgical margins were assessed intra-operatively with frozen sections. Microscopic examination of this specimen showed an epithelial tumor
infiltrating up to the skeletal muscle composed of tubules and pseudopapillary
structures showing similar cytological characteristics as the incisional
biopsy. The margins were free of neoplastic involvement (Figure 2). An
immunohistochemical panel was performed on formalin-fixed paraffin-embedded (FFPE) tissue and showed positivity for gross cystic disease
fluid protein (GCDFP)-15, cytokeratin( CK)-7, both supporting the sweat gland
nature of the lesion, and carcinoembryonic antigen (CEA), supporting the
malignant nature of the cells. CK 20, CDX2, and thyroid transcription factor-1 (TTF-1), markers
for colon and lung primaries, respectively, were negative, ruling out colon and
lung metastasis. The expression of human epidermal growth factor receptor 2
(HER2) was negative; however, there was a focal expression of adipophilin. No
recurrence of the lesion has been documented after 6mo follow up.
Figure 1 Slit-lamp
examination of the left eye for case 1 A: A notched, red, papillated, chalazion-like lesion; B: The lesion was associated with madarosis.
Figure 2 Histopathological
findings of case 1 A: On a low power view, a tubule forming tumor located in the skin surface
of the free margin of the eyelid and infiltrating up to the skeletal muscle is
seen. Note the lack of connection between the tumor and the epidermis (2.8×, H&E);
B: High power view reveals that tubules are lined by
large cells with irregular nuclei and prominent nucleoli; the cytoplasm is
eosinophilic (arrows). Note the presence of apical decapitation in the luminal
border of the cells (arrow heads), which is characteristic of apocrine
differentiation (20.4×, H&E); C: Higher power view showing multiple mitotic figures
and eosinophilic cytoplasm with decapitation secretions indicating the apocrine
differentiation (40×,
H&E).
Case 2 An 81-year-old male had a left upper lid tumor. The
lesion was excised and sent as a consultation case to our institution.
Histopathological slides of the eyelid specimen showed a nodular tumor attached
to the overlying epidermis with well-demarcated borders. The tumor was composed
of glandular and tubular structures with apocrine differentiation. On higher
magnification, the tubular structures were formed by epithelial cells with high
nuclear to cytoplasmic ratio and nuclei with irregular borders and clump
chromatic pattern with overlapping of the nuclei. The cytoplasm is eosinophilic
with decapitation of the apical border. The tumor has loose stroma intimately
associated with tumor islands with dense infiltration of lymphocytes and plasma
cells. Several atypical mitotic figures were seen [more than
10/high power fields (HPFs)]. Immunohistochemical studies were performed on FFPE
tissue and showed positivity for CK-7 and GCDFP-15, both supporting a sweat gland
origin, and positivity for CEA, supporting the malignant
nature of this apocrine lesion. CK20, CDX2, TTF-1 and prostate specific antigen
(PSA) were all negative, ruling out metastatic colon, lung, and prostatic
carcinomas, respectively. Estrogen receptor (ER), progesterone receptor (PR),
HER2 and adipophilin were all negative (Figure 3). A diagnosis of AC was made.
Figure 3 Histopathological findings of case 2 A: On a low power view, a well-demarcated tumor forming tubules is seen.
The tumor is connected to the epidermis (1.1×, H&E); B: On higher magnification, tubules are formed by cells with highly
pleomorphic, irregular and overlapped nuclei. Several mitotic figures are seen
(arrows) (40×, H&E); C: The neoplastic cells were negative for ER (40×); D: PR (40×).
Interestingly, the two AC in this series showed histopathological
differences. For example, in case 2 at low magnification, a well-demarcated
tumor with multiple attachments to the overlying epidermis can be seen;
however, an infiltrative pattern with ill-defined borders is noticed at low
magnification in case 1. Moreover, marked nuclear pleomorphism and numerous
mitotic figures are recognized at higher magnification in case 2. Conversely in
case 1, the nuclei are mildly hyperchromatic, the nuclear/cytoplasm ratio is
less striking, and there are fewer nuclear abnormalities. These features have
also been reported previously, showing a wide spectrum of histopathological
presentation ranging from infiltrative to well-circumscribed borders and low
cellular atypia to anaplastic features; therefore, in order to make the correct
diagnosis, the infiltrative pattern or malignant cellular atypia must be
demonstrated[2,4-6]. However, the delicate and limited
ocular and peri-ocular areas impose difficulties when it comes to obtaining
adequate biopsies. Therefore, this will also make diagnosis of apocrine carcinomas
of the eyelid more challenging.
Apocrine
neoplasms express GCDFP-15, which is a marker for adnexal tumors, including
breast[7]. Because they share common histological features and
immunohistochemical profiles, the diagnosis of primary cutaneous apocrine
carcinoma (PCAC) of the eyelid versus metastatic apocrine tumor of the breast
(MATB) to the eyelid is very difficult. However, differentiation is very
important as treatment plans may differ[7-8]. Immunohistochemicaly, both PCAC and MATB show strong
androgen receptor positivity[6-7,9]. Moreover, Piris et
al[7] reported 36% of PCAC staining positive for
adipophilin versus 88% for MATB. On the other hand, PCAC is more likely to
express ER and PR than cases of MATB (50% versus 12%, 29% versus 4%, respectively)[7,10]. They also reported that MATB more likely will have a strong and diffuse adipophilin staining (>50% of the
cells). HER2 positivity is exclusively seen in cases of MATB with HER2 genomic
expression[7,10]. Thus, there is no single marker available to
differentiate between the two entities; however, a panel of the aforementioned
markers can be helpful though non-diagnostic. Both our cases showed negativity
for HER2; however, only one showed focal positivity for adipophilin (Figure.4).
Moreover, ER and PR were negative in the second case where it was available.
Figure 4 Adipophilin expression in both our cases Adipophilin was focally expressed in case 1 (A) (24×); however, it was negative in case 2 (B) (12×).
Although AC usually arise de novo, they
can also arise from a pre-existing benign lesion, as in the case of
adenocarcinoma derived from an apocrine cyst[2,11].
Furthermore, the majority of apocrine carcinomas present clinically as a
recurrent eyelid lesion that is misdiagnosed as a chalazion[5,12-15]. Our
group has proposed previously the careful histopathological assessment of all
cases diagnosed clinically as chalazion, because a number of different benign,
premalignant, and malignant conditions may clinically masquerade as chalazion[16].
In conclusion, AC
of the eyelid can clinically and histopathologically mimic other lesions of the
same site. This adds to the difficulty in diagnosing such lesions.
Immunohistochemistry serves as a valuable tool for diagnosing lesions with
apocrine differentiation. Differentiating eyelid apocrine carcinoma from breast
metastatic carcinoma is a challenge and the clinico-pathologic correlation is
mandatory.
ACKNOWLEDGEMENTS
Conflicts of Interest: Aldrees SS, None;
Zoroquiain P, None; Alghamdi SA, None; Logan P, None; Kavalec C, None;
Burnier M, None.
REFERENCES
1 Al Baghli A,
Reddy SS, Reddy MA. Malignant nodular hidradenoma of the eyelid: a rare sweat
gland tumor. Middle East Afr J Ophthalmol
2010;17(4):374-376. [CrossRef] [PubMed] [PMC free article]
2
Barker-Griffith AE, Streeten BW, Charles NC. Moll gland neoplasms of the
eyelid: a clinical and pathological spectrum in 5 cases. Arch Ophthalmol 2006;124(11):1645-1649. [CrossRef] [PubMed]
3 Requenal L KH, Ackerman AB. Neoplasms With Apocrine Differentiation.
Philadelphia: Lippincott-Raven; 1998.
4 KIPKIE GF,
HAUST MD. Carcinoma of apocrine glands; report of case. AMA Arch Derm 1958;78(4):440-445. [CrossRef] [PubMed]
5 Figueira EC,
Danks J, Watanabe A, Khong JJ, Ong L, Selva D. Apocrine adenocarcinoma of the
eyelid: case series and review. Ophthal
Plast Reconstr Surg. 2013;29(6):417-423. [CrossRef] [PubMed]
6 Robson A,
Lazar AJ, Ben Nagi J, Hanby A, Grayson W, Feinmesser M, Granter SR, Seed P,
Warneke CL, McKee PH, Calonje E. Primary cutaneous apocrine carcinoma: a
clinico-pathologic analysis of 24 cases. Am
J Surg Pathol 2008;32(5):682-690. [CrossRef] [PubMed]
7 Piris A, Peng
Y, Boussahmain C, Essary LR, Gudewicz TM, Hoang MP. Cutaneous and mammary apocrine
carcinomas have different immunoprofiles. Hum
Pathol 2014;45(2):320-326. [CrossRef] [PubMed]
8 Japaze H,
Emina J, Diaz C, Schwam RJ, Gercovich N, Demonty G, Morgenfeld E, Rivarola E,
Gil Deza E, Gercovich FG. 'Pure' invasive apocrine carcinoma of the breast: a
new clinicopathological entity? Breast 2005;14(1):3-10. [CrossRef] [PubMed]
9 Le LP, Dias-Santagata D, Pawlak AC, Cosper AK, Nguyen AT, Selim MA,
Deng A, Horick NK, Iafrate AJ, Mihm MC Jr, Hoang MP. Apocrine-eccrine
carcinomas: molecular and immunohistochemical analyses. PLoS One 2012;7(10):e47290.
10 Tsutsumi Y.
Apocrine carcinoma as triple-negative breast cancer: novel definition of
apocrine-type carcinoma as estrogen/progesterone receptor-negative and androgen
receptor-positive invasive ductal carcinoma. Jpn J Clin Oncol 2012;42(5):375-386. [CrossRef]
[PubMed]
11 Seregard S.
Apocrine adenocarcinoma arising in Moll gland cystadenoma. Ophthalmology 1993;100(11):1716-1719. [CrossRef]
12 Akcay EK,
Simsek S, Cagil N, Belenli O, Gumus M. Apocrine adenocarcinoma of the right
eyelid and apocrine adenoma of the left maxillary sinus. Can J Ophthalmol 2008;43(5):609-610. [CrossRef]
[PubMed]
13 Shintaku M,
Tsuta K, Yoshida H, Tsubura A, Nakashima Y, Noda K. Apocrine adenocarcinoma of
the eyelid with aggressive biological behavior: report of a case. Pathol Int 2002;52(2):169-173. [CrossRef]
14 Valenzuela
AA, Cupp DG, Heathcote JG. Primary apocrine adenocarcinoma of the eyelid. Orbit 2012;31(5):316-318. [CrossRef] [PubMed]
15 Shields
JASCL. Eyelid, conjunctival, and orbital tumors : atlas and textbook.
Philadelphia: Lippincott Wiliams & Wilkins; 2008. 1p. [CrossRef] [PubMed]
