Apocrine adenocarcinoma of the eyelid

Sultan S Aldrees^1,2, Pablo Zoroquiain¹ , Sarah A Alghamdi¹, Patrick Logan¹ , Conrad Kavalec³, Miguel Burnier^1,3

¹The Henry C. Witelson Ocular Pathology Laboratory, McGill University, 1001 Boul Decarie, Montreal H4A 3J1, Canada

²Department of Ophthalmology, King Saud University, PO Box 245, Riyadh 11411, Saudi Arabia

³Department of Ophthalmology, McGill University, 5252 Boul de Maisonneuve ouest, Montreal H4A 3S5, Canada

Correspondence to: Pablo Zoroquiain. The Henry C. Witelson Ocular Pathology Laboratory, McGill University, 1001 Boul Decarie, Montreal H4A 3J1, Canada. zoroquiain@gmail.com
Received: 2015-06-14 Accepted: 2016-03-07

DOI:10.18240/ijo.2016.07.26

Citation: Aldrees SS, Zoroquiain P, Alghamdi SA, Logan P, Kavalec C, Burnier M. Apocrine adenocarcinoma of the eyelid. Int J Ophthalmol 2016;9(7):1086-1088

Dear Sir,

Sweat gland neoplasms of the ocular region are rare^[1]. Traditionally, these lesions are classified as either of eccrine or apocrine origin. The cardinal feature of apocrine tumors includes having apical decapitation secretions from the cells rather than forming simple secretory units with tubules, such as the case with their eccrine counterpart^[2-4]. Apocrine lesions can be both benign and malignant. There are only 22 cases of apocrine adenocarcinoma (AC) involving the eyelid in the English literature^[2,5]. In the present series, we show two primary AC of the eyelid with a broad morphological spectrum and with extensive immunohistochemical analysis.

Case 1 A 59-year-old female presented with a left lower lid lesion that has recurred for over 2y. The lesion was diagnosed clinically a chalazion and has been excised twice since it first appeared at another hospital without further histopathological evaluation; however, it progressed clinically to become red and nodular with projections and was associated with madarosis (Figure 1). On clinical examination, no lymph node enlargement was noticed. An incisional biopsy was then obtained and microscopic analysis of the tumor revealed a dermal tumor composed of epithelial cells forming tubules and papillary structures with no attachments to the overlying epidermis. At higher magnification, the cells were columnar to cuboidal with eosinophilic cytoplasm showing apical decapitation. The nuclei were mildly polymorphic with small nucleoli. The infiltrative tumor border reached the margins of the biopsy and vascular invasion was observed. A diagnosis of AC of the eyelid was made. The lesion was then excised and the surgical margins were assessed intra-operatively with frozen sections. Microscopic examination of this specimen showed an epithelial tumor infiltrating up to the skeletal muscle composed of tubules and pseudopapillary structures showing similar cytological characteristics as the incisional biopsy. The margins were free of neoplastic involvement (Figure 2). An immunohistochemical panel was performed on formalin-fixed paraffin-embedded (FFPE) tissue and showed positivity for gross cystic disease fluid protein (GCDFP)-15, cytokeratin( CK)-7, both supporting the sweat gland nature of the lesion, and carcinoembryonic antigen (CEA), supporting the malignant nature of the cells. CK 20, CDX2, and thyroid transcription factor-1 (TTF-1), markers for colon and lung primaries, respectively, were negative, ruling out colon and lung metastasis. The expression of human epidermal growth factor receptor 2 (HER2) was negative; however, there was a focal expression of adipophilin. No recurrence of the lesion has been documented after 6mo follow up.

Figure 1 Slit-lamp examination of the left eye for case 1 A: A notched, red, papillated, chalazion-like lesion; B: The lesion was associated with madarosis.

Figure 2 Histopathological findings of case 1 A: On a low power view, a tubule forming tumor located in the skin surface of the free margin of the eyelid and infiltrating up to the skeletal muscle is seen. Note the lack of connection between the tumor and the epidermis (2.8×, H&E); B: High power view reveals that tubules are lined by large cells with irregular nuclei and prominent nucleoli; the cytoplasm is eosinophilic (arrows). Note the presence of apical decapitation in the luminal border of the cells (arrow heads), which is characteristic of apocrine differentiation (20.4×, H&E); C: Higher power view showing multiple mitotic figures and eosinophilic cytoplasm with decapitation secretions indicating the apocrine differentiation (40×, H&E).

Case 2 An 81-year-old male had a left upper lid tumor. The lesion was excised and sent as a consultation case to our institution. Histopathological slides of the eyelid specimen showed a nodular tumor attached to the overlying epidermis with well-demarcated borders. The tumor was composed of glandular and tubular structures with apocrine differentiation. On higher magnification, the tubular structures were formed by epithelial cells with high nuclear to cytoplasmic ratio and nuclei with irregular borders and clump chromatic pattern with overlapping of the nuclei. The cytoplasm is eosinophilic with decapitation of the apical border. The tumor has loose stroma intimately associated with tumor islands with dense infiltration of lymphocytes and plasma cells. Several atypical mitotic figures were seen [more than 10/high power fields (HPFs)]. Immunohistochemical studies were performed on FFPE tissue and showed positivity for CK-7 and GCDFP-15, both supporting a sweat gland origin, and positivity for CEA, supporting the malignant nature of this apocrine lesion. CK20, CDX2, TTF-1 and prostate specific antigen (PSA) were all negative, ruling out metastatic colon, lung, and prostatic carcinomas, respectively. Estrogen receptor (ER), progesterone receptor (PR), HER2 and adipophilin were all negative (Figure 3). A diagnosis of AC was made.

Figure 3 Histopathological findings of case 2 A: On a low power view, a well-demarcated tumor forming tubules is seen. The tumor is connected to the epidermis (1.1×, H&E); B: On higher magnification, tubules are formed by cells with highly pleomorphic, irregular and overlapped nuclei. Several mitotic figures are seen (arrows) (40×, H&E); C: The neoplastic cells were negative for ER (40×); D: PR (40×).

Interestingly, the two AC in this series showed histopathological differences. For example, in case 2 at low magnification, a well-demarcated tumor with multiple attachments to the overlying epidermis can be seen; however, an infiltrative pattern with ill-defined borders is noticed at low magnification in case 1. Moreover, marked nuclear pleomorphism and numerous mitotic figures are recognized at higher magnification in case 2. Conversely in case 1, the nuclei are mildly hyperchromatic, the nuclear/cytoplasm ratio is less striking, and there are fewer nuclear abnormalities. These features have also been reported previously, showing a wide spectrum of histopathological presentation ranging from infiltrative to well-circumscribed borders and low cellular atypia to anaplastic features; therefore, in order to make the correct diagnosis, the infiltrative pattern or malignant cellular atypia must be demonstrated^[2,4-6]. However, the delicate and limited ocular and peri-ocular areas impose difficulties when it comes to obtaining adequate biopsies. Therefore, this will also make diagnosis of apocrine carcinomas of the eyelid more challenging.

Apocrine neoplasms express GCDFP-15, which is a marker for adnexal tumors, including breast^[7]. Because they share common histological features and immunohistochemical profiles, the diagnosis of primary cutaneous apocrine carcinoma (PCAC) of the eyelid versus metastatic apocrine tumor of the breast (MATB) to the eyelid is very difficult. However, differentiation is very important as treatment plans may differ^[7-8]. Immunohistochemicaly, both PCAC and MATB show strong androgen receptor positivity^[6-7,9]. Moreover, Piris et al^[7] reported 36% of PCAC staining positive for adipophilin versus 88% for MATB. On the other hand, PCAC is more likely to express ER and PR than cases of MATB (50% versus 12%, 29% versus 4%, respectively)^[7,10]. They also reported that MATB more likely will have a strong and diffuse adipophilin staining (>50% of the cells). HER2 positivity is exclusively seen in cases of MATB with HER2 genomic expression^[7,10]. Thus, there is no single marker available to differentiate between the two entities; however, a panel of the aforementioned markers can be helpful though non-diagnostic. Both our cases showed negativity for HER2; however, only one showed focal positivity for adipophilin (Figure.4). Moreover, ER and PR were negative in the second case where it was available.

Figure 4 Adipophilin expression in both our cases Adipophilin was focally expressed in case 1 (A) (24×); however, it was negative in case 2 (B) (12×).

Although AC usually arise de novo, they can also arise from a pre-existing benign lesion, as in the case of adenocarcinoma derived from an apocrine cyst^[2,11]. Furthermore, the majority of apocrine carcinomas present clinically as a recurrent eyelid lesion that is misdiagnosed as a chalazion^[5,12-15]. Our group has proposed previously the careful histopathological assessment of all cases diagnosed clinically as chalazion, because a number of different benign, premalignant, and malignant conditions may clinically masquerade as chalazion^[16].

In conclusion, AC of the eyelid can clinically and histopathologically mimic other lesions of the same site. This adds to the difficulty in diagnosing such lesions. Immunohistochemistry serves as a valuable tool for diagnosing lesions with apocrine differentiation. Differentiating eyelid apocrine carcinoma from breast metastatic carcinoma is a challenge and the clinico-pathologic correlation is mandatory.

ACKNOWLEDGEMENTS

Conflicts of Interest: Aldrees SS, None; Zoroquiain P, None; Alghamdi SA, None; Logan P, None; Kavalec C, None; Burnier M, None.

REFERENCES

1 Al Baghli A, Reddy SS, Reddy MA. Malignant nodular hidradenoma of the eyelid: a rare sweat gland tumor. Middle East Afr J Ophthalmol 2010;17(4):374-376. [CrossRef] [PubMed] [PMC free article]

2 Barker-Griffith AE, Streeten BW, Charles NC. Moll gland neoplasms of the eyelid: a clinical and pathological spectrum in 5 cases. Arch Ophthalmol 2006;124(11):1645-1649. [CrossRef] [PubMed]

3 Requenal L KH, Ackerman AB. Neoplasms With Apocrine Differentiation. Philadelphia: Lippincott-Raven; 1998.

4 KIPKIE GF, HAUST MD. Carcinoma of apocrine glands; report of case. AMA Arch Derm 1958;78(4):440-445. [CrossRef] [PubMed]

5 Figueira EC, Danks J, Watanabe A, Khong JJ, Ong L, Selva D. Apocrine adenocarcinoma of the eyelid: case series and review. Ophthal Plast Reconstr Surg. 2013;29(6):417-423. [CrossRef] [PubMed]

6 Robson A, Lazar AJ, Ben Nagi J, Hanby A, Grayson W, Feinmesser M, Granter SR, Seed P, Warneke CL, McKee PH, Calonje E. Primary cutaneous apocrine carcinoma: a clinico-pathologic analysis of 24 cases. Am J Surg Pathol 2008;32(5):682-690. [CrossRef] [PubMed]

7 Piris A, Peng Y, Boussahmain C, Essary LR, Gudewicz TM, Hoang MP. Cutaneous and mammary apocrine carcinomas have different immunoprofiles. Hum Pathol 2014;45(2):320-326. [CrossRef] [PubMed]

8 Japaze H, Emina J, Diaz C, Schwam RJ, Gercovich N, Demonty G, Morgenfeld E, Rivarola E, Gil Deza E, Gercovich FG. 'Pure' invasive apocrine carcinoma of the breast: a new clinicopathological entity? Breast 2005;14(1):3-10. [CrossRef] [PubMed]

9 Le LP, Dias-Santagata D, Pawlak AC, Cosper AK, Nguyen AT, Selim MA, Deng A, Horick NK, Iafrate AJ, Mihm MC Jr, Hoang MP. Apocrine-eccrine carcinomas: molecular and immunohistochemical analyses. PLoS One 2012;7(10):e47290.

10 Tsutsumi Y. Apocrine carcinoma as triple-negative breast cancer: novel definition of apocrine-type carcinoma as estrogen/progesterone receptor-negative and androgen receptor-positive invasive ductal carcinoma. Jpn J Clin Oncol 2012;42(5):375-386. [CrossRef] [PubMed]

11 Seregard S. Apocrine adenocarcinoma arising in Moll gland cystadenoma. Ophthalmology 1993;100(11):1716-1719. [CrossRef]

12 Akcay EK, Simsek S, Cagil N, Belenli O, Gumus M. Apocrine adenocarcinoma of the right eyelid and apocrine adenoma of the left maxillary sinus. Can J Ophthalmol 2008;43(5):609-610. [CrossRef] [PubMed]

13 Shintaku M, Tsuta K, Yoshida H, Tsubura A, Nakashima Y, Noda K. Apocrine adenocarcinoma of the eyelid with aggressive biological behavior: report of a case. Pathol Int 2002;52(2):169-173. [CrossRef]

14 Valenzuela AA, Cupp DG, Heathcote JG. Primary apocrine adenocarcinoma of the eyelid. Orbit 2012;31(5):316-318. [CrossRef] [PubMed]

15 Shields JASCL. Eyelid, conjunctival, and orbital tumors : atlas and textbook. Philadelphia: Lippincott Wiliams & Wilkins; 2008. 1p. [CrossRef] [PubMed]
